Details

  • •Low-voltage industrial components
  • •Frequency converter =< 1 kV
  • •1 KOM
  • •SCHNEIDER

Technical specifications

Depth236mm
With control elementYes
Number of digital outputs1
Width171mm
Number of digital inputs8
Height409mm
Number of analogue inputs3
Number of HW-interfaces RS-4220
Supporting protocol for SUCONETNo
Number of HW-interfaces parallel0
Supporting protocol for LONNo
Supporting protocol for other bus systemsYes
Supporting protocol for DeviceNetYes
Number of HW-interfaces other0
Supporting protocol for INTERBUSNo
Supporting protocol for ASINo
Supporting protocol for ModbusNo
Supporting protocol for SERCOSNo
Supporting protocol for CANYes
Supporting protocol for PROFIBUSYes
Number of HW-interfaces RS-2320
Number of HW-interfaces USB0
With optical interfaceYes
With PC connectionNo
Supporting protocol for Data-HighwayNo
Number of HW-interfaces RS-4853
Number of HW-interfaces serial TTY0
Supporting protocol for TCP/IPNo
Number of analogue outputs2
Supporting protocol for KNXNo
Number of HW-interfaces industrial Ethernet0
Max. output voltage480V
Supporting protocol for DeviceNet SafetyNo
Max. output at quadratic load at rated output voltage11kW
Relative symmetric net frequency tolerance5%
Supporting protocol for SafetyBUS pNo
Supporting protocol for PROFIsafeNo
Supporting protocol for AS-Interface Safety at WorkNo
Supporting protocol for EtherNet/IPYes
Application in domestic- and commercial area permittedYes
Supporting protocol for Foundation FieldbusNo
Application in industrial area permittedYes
Max. output frequency500Hz
Supporting protocol for PROFINET IOYes
Type of converterU converter
Integrated breaking resistanceNo
Supporting protocol for PROFINET CBANo
Mains frequency50/60 Hz
Number of interfaces PROFINET0
Supporting protocol for INTERBUS-SafetyNo
4-quadrant operation possibleYes
Relative symmetric net voltage tolerance10%
Supporting protocol for BACnetNo
Degree of protection (IP)IP21
Mains voltage380 - 480V
Number of phases output3
Number of phases input3
Max. output at linear load at rated output voltage11kW
Nominal output current I2N23.5A
