Details
- •Low-voltage industrial components
- •Frequency converter =< 1 kV
- •1 KOM
- •SCHNEIDER
Technical specifications
Number of HW-interfaces other0
Width55mm
Supporting protocol for ASINo
Number of digital outputs2
Supporting protocol for PROFIBUSNo
Number of digital inputs6
Supporting protocol for TCP/IPNo
Number of HW-interfaces industrial Ethernet0
Height150mm
Depth146mm
Number of HW-interfaces serial TTY0
Number of HW-interfaces RS-4851
Number of HW-interfaces parallel0
Number of HW-interfaces RS-2320
With optical interfaceNo
Number of HW-interfaces RS-4222
Number of analogue outputs1
Number of analogue inputs3
Supporting protocol for LONNo
With control elementYes
Number of HW-interfaces USB0
Supporting protocol for CANYes
Supporting protocol for INTERBUSNo
Max. output frequency16Hz
Application in domestic- and commercial area permittedYes
Max. output at quadratic load at rated output voltage0.2kW
With PC connectionNo
Supporting protocol for DeviceNetNo
Supporting protocol for KNXNo
Supporting protocol for Data-HighwayNo
Mains voltage220 - 220V
Number of phases input1
Application in industrial area permittedYes
Supporting protocol for ModbusYes
Type of converterDirect converter
Mains frequency50/60 Hz
Supporting protocol for SERCOSNo
Integrated breaking resistanceYes
Number of interfaces PROFINET0
Max. output at linear load at rated output voltage0.2kW
4-quadrant operation possibleNo
Degree of protection (IP)IP20
Number of phases output3
Supporting protocol for other bus systemsNo
Supporting protocol for INTERBUS-SafetyNo
Supporting protocol for SUCONETNo
Relative symmetric net frequency tolerance5%
Relative symmetric net voltage tolerance10%
Supporting protocol for DeviceNet SafetyNo
Supporting protocol for AS-Interface Safety at WorkNo
Supporting protocol for EtherNet/IPNo
Supporting protocol for PROFINET CBANo
Supporting protocol for PROFINET IONo
Supporting protocol for BACnetNo
Supporting protocol for PROFIsafeNo
Supporting protocol for Foundation FieldbusNo
Max. output voltage240V
Nominal output current I2N1.5A
Supporting protocol for SafetyBUS pNo
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
LXM28AU02M3X | LEXIUM28 IO and CAN drive - 200W
