Details

  • •Low-voltage industrial components
  • •Frequency converter =< 1 kV
  • •1 KOM
  • •SCHNEIDER

Technical specifications

Number of digital inputs6
Number of digital outputs2
With control elementYes
Width55mm
Depth170mm
Height150mm
Number of analogue inputs3
Number of analogue outputs1
Supporting protocol for LONNo
Number of HW-interfaces RS-2320
Number of HW-interfaces industrial Ethernet0
Number of HW-interfaces RS-4851
Supporting protocol for KNXNo
Supporting protocol for PROFIBUSNo
Supporting protocol for INTERBUSNo
With optical interfaceNo
Supporting protocol for Data-HighwayNo
Number of HW-interfaces RS-4222
Number of HW-interfaces serial TTY0
Supporting protocol for ASINo
Supporting protocol for TCP/IPNo
Number of HW-interfaces USB0
Number of HW-interfaces other0
Number of HW-interfaces parallel0
Supporting protocol for CANYes
Supporting protocol for ModbusYes
Supporting protocol for DeviceNetNo
Supporting protocol for SUCONETNo
Supporting protocol for SERCOSNo
With PC connectionNo
Supporting protocol for other bus systemsNo
Supporting protocol for DeviceNet SafetyNo
Max. output at quadratic load at rated output voltage1kW
Number of interfaces PROFINET0
Supporting protocol for INTERBUS-SafetyNo
4-quadrant operation possibleNo
Application in industrial area permittedYes
Supporting protocol for AS-Interface Safety at WorkNo
Relative symmetric net voltage tolerance10%
Relative symmetric net frequency tolerance5%
Max. output frequency16Hz
Application in domestic- and commercial area permittedYes
Integrated breaking resistanceYes
Mains frequency50/60 Hz
Type of converterDirect converter
Supporting protocol for PROFINET IONo
Supporting protocol for EtherNet/IPNo
Supporting protocol for SafetyBUS pNo
Supporting protocol for PROFIsafeNo
Supporting protocol for Foundation FieldbusNo
Max. output voltage240V
Supporting protocol for PROFINET CBANo
Supporting protocol for BACnetNo
Degree of protection (IP)IP20
Mains voltage220 - 220V
Number of phases output3
Number of phases input1
Max. output at linear load at rated output voltage1kW
Nominal output current I2N7A
