  • •Low-voltage industrial components
  • •Frequency converter =< 1 kV
  • •Minimum order quantity: 1 pcs
  • •SCHNEIDER

Technical specifications

Number of analogue inputs3
Width68mm
Depth237mm
Number of HW-interfaces RS-2320
Number of digital inputs6
With control elementYes
Number of digital outputs2
Supporting protocol for LONNo
Height270mm
Number of analogue outputs1
Number of HW-interfaces industrial Ethernet1
With optical interfaceNo
Number of HW-interfaces USB0
Supporting protocol for PROFIBUSYes
Number of HW-interfaces parallel0
Supporting protocol for TCP/IPNo
Supporting protocol for ASINo
Number of HW-interfaces serial TTY0
Number of HW-interfaces RS-4851
Number of HW-interfaces other0
Number of HW-interfaces RS-4220
Supporting protocol for Data-HighwayNo
Supporting protocol for ModbusYes
Supporting protocol for KNXNo
Supporting protocol for CANYes
Supporting protocol for SUCONETNo
Supporting protocol for other bus systemsNo
Supporting protocol for INTERBUSNo
Supporting protocol for DeviceNetYes
Mains frequency50/60 Hz
Supporting protocol for INTERBUS-SafetyNo
Supporting protocol for SERCOSNo
4-quadrant operation possibleNo
With PC connectionYes
Application in industrial area permittedYes
Number of interfaces PROFINET0
Type of converterOther
Application in domestic- and commercial area permittedYes
Max. output frequency8Hz
Integrated breaking resistanceNo
Max. output at quadratic load at rated output voltage0.3kW
Supporting protocol for EtherNet/IPYes
Supporting protocol for PROFINET CBANo
Relative symmetric net voltage tolerance10%
Relative symmetric net frequency tolerance5%
Supporting protocol for AS-Interface Safety at WorkNo
Supporting protocol for Foundation FieldbusNo
Supporting protocol for DeviceNet SafetyNo
Supporting protocol for PROFINET IOYes
Supporting protocol for PROFIsafeNo
Supporting protocol for BACnetNo
Max. output voltage230V
Supporting protocol for SafetyBUS pNo
Degree of protection (IP)IP20
Mains voltage115 - 230V
Number of phases outputOther
Number of phases input1
Max. output at linear load at rated output voltage0.3kW
Nominal output current I2N1.5A
