LZ1H6X53BD | Motorski Pok. Dir. 1,5-6,5A 24VDC

Name: LZ1H6X53BD | Motorski Pok. Dir. 1,5-6,5A 24VDC
Brand: SCHNEIDER
Price: 228 EUR
Availability: BackOrder

Code: 1758363

ManufacturerSchneider

Catalog numberLZ1H6X53BD

TypeLow-voltage industrial components

EAN code3606485421148

Details

•Low-voltage industrial components
•Motor starter/Motor starter combination
•1 KOM
•SCHNEIDER

Technical specifications

Rated operation power at AC-3, 400 V3kW

Width22.6mm

Number of auxiliary contacts as normally closed contact0

With transformerNo

Rated operation current Ie9A

Overload release current setting1.5 - 6.5A

Height107.5mm

Number of indicator lights3

Number of command positions0

Suitable for emergency stopNo

Number of auxiliary contacts as normally open contact0

Depth113.4mm

Supporting protocol for LONNo

Supporting protocol for INTERBUSNo

Supporting protocol for TCP/IPNo

Supporting protocol for PROFIBUSNo

Supporting protocol for ASINo

Supporting protocol for CANNo

Supporting protocol for ModbusNo

Rail mounting possibleYes

Supporting protocol for SUCONETNo

External reset possibleYes

Supporting protocol for DeviceNetNo

Supporting protocol for other bus systemsNo

Supporting protocol for Data-HighwayNo

Degree of protection (IP)IP20

Supporting protocol for INTERBUS-SafetyNo

Rated control supply voltage Us at AC 50HZ- - -V

Type of electrical connection for auxiliary- and control current circuitSpring clamp connection

Supporting protocol for AS-Interface Safety at WorkNo

With fuseNo

Supporting protocol for SERCOSNo

Release classCLASS 10

Rated control supply voltage Us at AC 60HZ- - -V

Type of electrical connection of main circuitSpring clamp connection

With short-circuit releaseNo

Rated control supply voltage Us at DC24 - 24V

Supporting protocol for DeviceNet SafetyNo

Supporting protocol for PROFIsafeNo

Voltage type for actuatingDC

Rated operation power at AC-3, 230 V, 3-phase1.5kW

Rated conditional short-circuit current, type 1, 600 Y/347 V-A

Supporting protocol for PROFINET CBANo

Temperature compensated overload protectionYes

Rated conditional short-circuit current, type 1, 480 Y/277 V-A

Supporting protocol for PROFINET IONo

Supporting protocol for Foundation FieldbusNo

Type of motor starterDirect online starter (DOL)

Rated power, 460 V, 60 Hz, 3-phase3kW

Supporting protocol for SafetyBUS pNo

Rated conditional short-circuit current, type 2, 400 V-A

Rated power, 575 V, 60 Hz, 3-phase-kW

Rated conditional short-circuit current, type 2, 230 V-A

Ambient temperature, upper operating limit70°C

Rated operation current at AC-3, 400 V9A

Supporting protocol for EtherNet/IPNo
