Details
- •Low-voltage switchgear and control gear (automation)
- •Motor starter/motor starter combination
- •1 KOM
- •SCHNEIDER
Technical specifications
Width22.6mm
Depth113.4mm
Height107.5mm
Number of auxiliary contacts as normally open contact0
With transformerNo
Suitable for emergency stopYes
Number of command positions0
Supporting protocol for TCP/IPNo
Number of auxiliary contacts as normally closed contact0
Number of indicator lights4
Overload release current setting0.18 - 2.4A
Rated operation current Ie2.4A
Supporting protocol for LONNo
Supporting protocol for CANNo
Supporting protocol for INTERBUSNo
Rated control supply voltage Us at AC 60HZ- - -V
Supporting protocol for SUCONETNo
Supporting protocol for Data-HighwayNo
Supporting protocol for PROFIBUSNo
Supporting protocol for DeviceNetNo
Supporting protocol for ASINo
Supporting protocol for ModbusNo
Rated control supply voltage Us at AC 50HZ- - -V
Rated operation power at AC-3, 400 V0.75kW
Rail mounting possibleYes
External reset possibleYes
Supporting protocol for other bus systemsNo
Rated control supply voltage Us at DC24 - 24V
Supporting protocol for DeviceNet SafetyNo
Release classCLASS 10
Supporting protocol for AS-Interface Safety at WorkNo
Supporting protocol for INTERBUS-SafetyNo
With fuseNo
Degree of protection (IP)IP20
Type of electrical connection for auxiliary- and control current circuitSpring clamp connection
Supporting protocol for SERCOSNo
Supporting protocol for PROFINET CBANo
Supporting protocol for PROFIsafeNo
Supporting protocol for Foundation FieldbusNo
Supporting protocol for EtherNet/IPNo
Supporting protocol for PROFINET IONo
Rated power, 460 V, 60 Hz, 3-phase0.75kW
Voltage type for actuatingDC
Supporting protocol for SafetyBUS pNo
Type of motor starterReversing starter
Rated operation power at AC-3, 230 V, 3-phase0.37kW
Type of electrical connection of main circuitSpring clamp connection
Rated conditional short-circuit current, type 2, 400 V-A
Rated power, 575 V, 60 Hz, 3-phase-kW
Temperature compensated overload protectionYes
With short-circuit releaseNo
Rated operation current at AC-3, 400 V2.4A
Ambient temperature, upper operating limit70°C
Rated conditional short-circuit current, type 1, 600 Y/347 V-A
Rated conditional short-circuit current, type 1, 480 Y/277 V-A
Rated conditional short-circuit current, type 2, 230 V-A
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
LZ8H2X43BD | Motorski Pok. Reverz. 0,18-2,4A 24VDC FS
