LZ8H6X53BD | Motorski Pok. Reverz. 1,5-6,5A 24VDC FS

Name: LZ8H6X53BD | Motorski Pok. Reverz. 1,5-6,5A 24VDC FS
Brand: SCHNEIDER
Price: 239 EUR
Availability: BackOrder

Code: 1758387

ManufacturerSchneider Electric

Catalog numberLZ8H6X53BD

TypeLow-voltage industrial components

EAN code3606485421261

Details

•Low-voltage industrial components
•Motor starter/Motor starter combination
•1 KOM
•SCHNEIDER

Technical specifications

Width22.6mm

Supporting protocol for CANNo

Supporting protocol for INTERBUSNo

Number of command positions0

Suitable for emergency stopYes

Supporting protocol for LONNo

Number of auxiliary contacts as normally open contact0

Depth113.4mm

Height107.5mm

Supporting protocol for PROFIBUSNo

Supporting protocol for ASINo

Supporting protocol for ModbusNo

With transformerNo

Supporting protocol for TCP/IPNo

Number of indicator lights4

Number of auxiliary contacts as normally closed contact0

Supporting protocol for Data-HighwayNo

With short-circuit releaseNo

Supporting protocol for DeviceNetNo

Rated control supply voltage Us at AC 60HZ- - -V

With fuseNo

Rated control supply voltage Us at AC 50HZ- - -V

External reset possibleYes

Type of electrical connection of main circuitSpring clamp connection

Supporting protocol for other bus systemsNo

Supporting protocol for SUCONETNo

Rail mounting possibleYes

Supporting protocol for SERCOSNo

Supporting protocol for INTERBUS-SafetyNo

Supporting protocol for SafetyBUS pNo

Supporting protocol for PROFINET IONo

Release classCLASS 10

Type of electrical connection for auxiliary- and control current circuitSpring clamp connection

Supporting protocol for DeviceNet SafetyNo

Supporting protocol for AS-Interface Safety at WorkNo

Supporting protocol for PROFIsafeNo

Supporting protocol for Foundation FieldbusNo

Supporting protocol for EtherNet/IPNo

Supporting protocol for PROFINET CBANo

Rated conditional short-circuit current, type 2, 230 V-A

Temperature compensated overload protectionYes

Rated power, 575 V, 60 Hz, 3-phase-kW

Rated conditional short-circuit current, type 1, 480 Y/277 V-A

Rated conditional short-circuit current, type 2, 400 V-A

Voltage type for actuatingDC

Rated conditional short-circuit current, type 1, 600 Y/347 V-A

Ambient temperature, upper operating limit70°C

Rated operation power at AC-3, 230 V, 3-phase1.5kW

Rated power, 460 V, 60 Hz, 3-phase3kW

Rated operation power at AC-3, 400 V3kW

Rated operation current Ie9A

Overload release current setting1.5 - 6.5A

Degree of protection (IP)IP20

Rated control supply voltage Us at DC24 - 24V

Type of motor starterReversing starter

Rated operation current at AC-3, 400 V6.5A
