Details
- •Low-voltage industrial components
- •Switch disconnector (low voltage)
- •1 KOM
- •HAGER
Technical specifications
Width75mm
Number of auxiliary contacts as normally open contact0
Rated operation power at AC-3, 400 V-kW
Number of auxiliary contacts as normally closed contact0
Depth96mm
Height130mm
Degree of protection (IP), front sideIP40
Conditioned rated short-circuit current Iq-kA
Rated permanent current Iu160A
Rated operating voltage220 - 690V
Number of auxiliary contacts as change-over contact0
Number of poles3
Version as main switchYes
Type of electrical connection of main circuitScrew connection
Type of control elementToggle
InterlockableYes
Motor drive integratedNo
Version as emergency stop installationYes
Number of switches1
Suitable for front mounting 4-holeNo
Colour control elementGrey
Device constructionBuilt-in device fixed built-in technique
Version as safety switchNo
Suitable for intermediate mountingNo
Rated short-time withstand current lcw2kA
Suitable for front mounting centreNo
Voltage release optionalYes
Version as maintenance-/service switchYes
Version as reversing switchNo
Switching power at 400 V105kW
Suitable for floor mountingYes
Rated operation power at AC-23, 400 V163kW
Suitable for distribution board installationYes
Rated permanent current at AC-21, 400 V160A
Max. rated operation voltage Ue AC690V
Motor drive optionalNo
Rated permanent current at AC-23, 400 V160A
With pre-assembled cablingNo
Degree of protection (NEMA)Other
