Details
- •Low-voltage industrial components
- •Switch disconnector
- •1 KOM
- •HAGER
Technical specifications
Rated operation power at AC-3, 400 V-kW
Number of auxiliary contacts as normally closed contact0
Rated permanent current Iu400A
Number of poles3
Number of auxiliary contacts as normally open contact0
Suitable for front mounting centreNo
Conditioned rated short-circuit current Iq-kA
Number of switches1
Version as maintenance-/service switchYes
Motor drive integratedNo
Max. rated operation voltage Ue AC690V
Degree of protection (IP), front sideIP40
Rated operating voltage220 - 690V
Device constructionBuilt-in device fixed built-in technique
Number of auxiliary contacts as change-over contact0
Suitable for front mounting 4-holeNo
Version as safety switchYes
Rated short-time withstand current lcw5kA
Rated operation power at AC-23, 400 V180kW
Version as main switchYes
Colour control elementBlack
Voltage release optionalYes
Suitable for intermediate mountingNo
Motor drive optionalYes
Suitable for distribution board installationYes
InterlockableYes
Type of control elementToggle
Type of electrical connection of main circuitCable clamp
Version as emergency stop installationNo
Suitable for floor mountingYes
Rated permanent current at AC-21, 400 V400A
Degree of protection (NEMA)Other
Version as reversing switchNo
Switching power at 400 V263kW
