HCD401H
Code: 1761803
Details
- •Low-voltage industrial components
- •Switch disconnector
- •1 KOM
- •HAGER
Technical specifications
Number of poles4
Type of control elementToggle
Number of auxiliary contacts as normally open contact0
Rated permanent current Iu400A
Number of auxiliary contacts as normally closed contact0
Motor drive optionalYes
Motor drive integratedNo
Device constructionBuilt-in device fixed built-in technique
Number of auxiliary contacts as change-over contact0
Type of electrical connection of main circuitCable clamp
Rated operation power at AC-3, 400 V-kW
Suitable for floor mountingYes
Suitable for intermediate mountingNo
Suitable for distribution board installationYes
Degree of protection (NEMA)Other
Degree of protection (IP), front sideIP40
Conditioned rated short-circuit current Iq-kA
Max. rated operation voltage Ue AC690V
Rated operation power at AC-23, 400 V180kW
Rated operating voltage220 - 690V
Colour control elementBlack
Suitable for front mounting 4-holeNo
Voltage release optionalYes
Version as maintenance-/service switchYes
InterlockableYes
Switching power at 400 V263kW
Number of switches1
Rated short-time withstand current lcw5kA
Version as safety switchYes
Suitable for front mounting centreNo
Version as emergency stop installationNo
Rated permanent current at AC-21, 400 V400A
Version as reversing switchNo
Version as main switchYes
