Details
- •Low-voltage industrial components
- •Switch disconnector
- •1 KOM
- •HAGER
Technical specifications
Number of auxiliary contacts as normally closed contact0
Rated operation power at AC-3, 400 V-kW
Number of auxiliary contacts as normally open contact0
Rated operating voltage380 - 415V
Conditioned rated short-circuit current Iq50kA
Number of auxiliary contacts as change-over contact0
Type of electrical connection of main circuitScrew connection
Number of poles3
Rated permanent current Iu63A
InterlockableYes
Motor drive integratedNo
Degree of protection (IP), front sideIP20
Rated operation power at AC-23, 400 V28kW
Colour control elementGrey
Version as safety switchYes
Suitable for floor mountingYes
Type of control elementShort thumb-grip
Rated short-time withstand current lcw1.5kA
Motor drive optionalNo
Version as main switchYes
Version as maintenance-/service switchYes
Suitable for front mounting 4-holeNo
Voltage release optionalNo
Max. rated operation voltage Ue AC415V
Suitable for intermediate mountingNo
Rated permanent current at AC-21, 400 V63A
Device constructionComplete device in housing
Suitable for front mounting centreNo
Suitable for distribution board installationYes
Switching power at 400 V41kW
Version as reversing switchYes
Version as emergency stop installationNo
