Details
- •Circuit breakers and fuses
- •Miniature circuit breaker (MCB)
- •1 KOM
- •HAGER
Technical specifications
Rated current63A
Built-in depth70mm
Voltage typeAC
Current limiting class3
Rated voltage400V
Pollution degree2
Release characteristicC
Over voltage category3
Frequency50 - 60Hz
Suitable for flush-mounted installationYes
Degree of protection (IP)IP20
Additional equipment possibleYes
Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V10kA
Concurrently switching neutral conductorNo
Number of protected poles2
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V15kA
Width in number of modular spacings2
Number of poles (total)2
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V30kA
Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V10kA
