Details

  • •Circuit breakers and fuses
  • •Miniature circuit breaker (MCB)
  • •1 KOM
  • •HAGER

Technical specifications

Suitable for flush-mounted installationYes
Frequency50 - 60Hz
Additional equipment possibleYes
Pollution degree2
Degree of protection (IP)IP20
Voltage typeAC
Concurrently switching neutral conductorNo
Built-in depth25mm
Rated insulation voltage Ui400V
Current limiting class332
Over voltage category400
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V10kA
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V10kA
Rated impulse withstand voltage Uimp400kV
Number of protected poles3
Rated voltage400V
Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V10kA
Width in number of modular spacings3
Rated current32A
Release characteristicC
Number of poles (total)3
Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V10kA
