Details
- •Earthing, lightning and surge protection
- •Surge protection device for power supply systems
- •1 KOM
- •HAGER
Technical specifications
Category type 2Yes
Degree of protection (IP)IP20
Mounting methodDIN rail (top hat rail) 35 mm
Nominal voltage DC-V
Voltage protection level1.5kV
Max. continuous voltage DC-V
Signalling at the deviceOptic
With remote signalling contactYes
Nominal discharge surge current (8/20)20kA
System configurationTN-S
Nominal voltage AC400V
Type of poles4
Voltage protection level L-N1.5kV
Max. continuous voltage AC275V
Max. PV-voltage0V
Short-circuit-proofNo
Voltage protection level N-PE1.5kV
Max. conductor cross section flexible (fine-strand)-mm²
Max. conductor cross section solid (solid, stranded)-mm²
Integrated backup fuseNo
Related products
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
SPN417
