Details
- •Installation bus systems
- •Switch actuator for bus system
- •1 KOM
- •HAGER
Technical specifications
Output power2300W
Rated current10A
Mounting methodSurface mounted (plaster)
Bus system PowernetNo
Rated operating voltage195 - 253V
Bus system radio frequentYes
Max. switching current10A
Number of digital inputs0
Bus system KNXYes
Max. number of switching contacts1
Suitable for C-loadNo
Max. switching power2300W
Bus system LONNo
Width in number of modular spacings0
Other bus systemsNone
With bus connectionNo
Degree of protection (IP)IP55
Min. depth of built-in installation box40mm
With LED indicationYes
Different phases connectableNo
Radio frequent bidirectionalYes
Bus system KNX radioYes
Max. switching power LED100W
Local operation/hand operationYes
Bus module detachableNo
Modular expandabilityNo
