TRE202
Code: 1763100
Details
- •Installation bus systems
- •Switch actuator for bus system
- •1 KOM
- •HAGER
Technical specifications
Bus system LONNo
Bus system KNX radioYes
Bus system radio frequentYes
Bus system KNXYes
Other bus systemsNone
Mounting methodSurface mounted (plaster)
Bus system PowernetNo
Radio frequent bidirectionalYes
Width in number of modular spacings0
Local operation/hand operationYes
With LED indicationYes
Max. switching power2300W
Output power2300W
Number of digital inputs0
Suitable for C-loadNo
Max. switching power LED100W
Max. number of switching contacts2
Max. switching current10A
Rated current10A
Rated operating voltage195 - 253V
Different phases connectableNo
Bus module detachableNo
Modular expandabilityNo
Degree of protection (IP)IP55
Min. depth of built-in installation box40mm
With bus connectionNo
