Details
- •Installation bus systems
- •Switch actuator for bus system
- •1 KOM
- •HAGER
Technical specifications
Mounting methodDRA (DIN-rail adapter)
Bus system radio frequentNo
Rated operating voltage230 - 230V
Bus system PowernetNo
Bus system KNXYes
Rated current10A
Output power1200W
Max. switching power9000W
Max. number of switching contacts10
Number of digital inputs0
With bus connectionYes
Bus system LONNo
Other bus systemsNone
Width in number of modular spacings6
Radio frequent bidirectionalNo
Max. switching current10A
Different phases connectableYes
Max. switching power LED276W
Local operation/hand operationYes
Degree of protection (IP)IP20
With LED indicationYes
Bus module detachableNo
Suitable for C-loadNo
Bus system KNX radioNo
Modular expandabilityNo
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
TYA610B
Why Register?
- View wholesale prices with discounts
- Real-time stock availability
- Access invoices and dispatch notes
- Order history and frequently ordered items
- Exclusive B2B offers
and much more...
Details
- Installation bus systems
- Switch actuator for bus system
- 1 KOM
- HAGER
DetailsTechnical specifications
Technical specifications
Mounting method
DRA (DIN-rail adapter)
Bus system radio frequent
Rated operating voltage
230 .. 230V
Bus system Powernet
Bus system KNX
Rated current
10A
Output power
1200W
Max. switching power
9000W
Max. number of switching contacts
10
Number of digital inputs
0
With bus connection
Bus system LON
Other bus systems
None
Width in number of modular spacings
6
Radio frequent bidirectional
Max. switching current
10A
Different phases connectable
Max. switching power LED
276W
Local operation/hand operation
Degree of protection (IP)
IP20
With LED indication
Bus module detachable
Suitable for C-load
Bus system KNX radio
Modular expandability
VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user.
