WS171V
Code: 1763833
Details
- •Domestic switching devices
- •Socket outlet
- •1 KOM
- •HAGER
Technical specifications
ModelProtective contact (SCHUKO)
Mounting methodOther
Material qualityThermoplastic
RAL-number (similar)6029
Surface finishingMatt
MaterialPlastic
Surface protectionLacquered
Type of fasteningSnap mounting (engagement)
ColourGreen
Halogen freeNo
Impact strengthIK07
Suitable for degree of protection (IP)IP2X
TransparentNo
Label space/information surfaceNo
Number of modules (module system)3
Width of device90mm
Nominal voltage250V
Height of device45mm
Frequency50 - 60Hz
Number of units-
Connection typePush-in clamp
Depth of device42.5mm
With hinged lidNo
Imprint/indicationWithout imprint
LockableNo
Insulated mountingYes
Over voltage protectionNo
With on/off switchNo
Rotated central insertNo
For heavy conditions (according to VDE)No
Fault current protectionNo
Eject-mechanismNo
With built-in USB power supplyNo
With function lightingNo
Rated fault current0mA
With enhanced contact protectionNo
With miniature fuseNo
With orientation lightingNo
With loop through functionNo
Number of socket outlets switchable0
CoverOther
Phase pickupL1
Nominal current16A
