Details
- •Circuit breakers and fuses
- •Earth leakage circuit breaker
- •1 KOM
- •LEGRAND
Technical specifications
Rated current6A
Surge current capacity-kA
Built-in depth44.5mm
Rated fault current0.01A
Release characteristicC
Rated voltage230V
Rated insulation voltage Ui-V
Leakage current typeOther
Current limiting class1
Pollution degree-
Over voltage category-
Degree of protection (IP)IP20
Frequency50/60 Hz
Number of protected poles1
Width in number of modular spacings45.1
Rated short-circuit breaking capacity according to IEC 60947-21.5kA
Rated impulse withstand voltage Uimp-kV
Connectable conductor cross section multi-wired- - -mm²
Connectable conductor cross section solid-core2.5 - 2.5mm²
Concurrently switching neutral conductorYes
Rated short-circuit breaking capacity Icn according to EN 61009-11.5kA
Anti-nuisance tripping versionNo
With interlocking deviceNo
Rated short-circuit breaking capacity according to EN 610091.5kA
Number of poles (total)1
Ambient temperature during operating-5 - 50°C
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
HC4305/6 | RCD+MCB 1P+N 6A 10MA 1500A-2M
