Details
- •Circuit breakers and fuses
- •Earth leakage circuit breaker
- •1 KOM
- •LEGRAND
Technical specifications
Built-in depth44.5mm
Rated voltage230V
Rated current6A
Rated fault current0.01A
Surge current capacity-kA
Width in number of modular spacings45.1
Release characteristicC
Current limiting class1
Rated insulation voltage Ui-V
Leakage current typeOther
Over voltage category-
Frequency50/60 Hz
Pollution degree-
Degree of protection (IP)IP20
Connectable conductor cross section solid-core2.5 - 2.5mm²
Number of protected poles1
Ambient temperature during operating-5 - 50°C
Rated short-circuit breaking capacity according to IEC 60947-21.5kA
Anti-nuisance tripping versionNo
Connectable conductor cross section multi-wired- - -mm²
With interlocking deviceNo
Number of poles (total)1
Concurrently switching neutral conductorYes
Rated impulse withstand voltage Uimp-kV
Rated short-circuit breaking capacity according to EN 610091.5kA
Rated short-circuit breaking capacity Icn according to EN 61009-11.5kA
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
HS4305/6 | RCD+MCB 1P+N 6A 10MA 1500A-2M
Why Register?
- View wholesale prices with discounts
- Real-time stock availability
- Access invoices and dispatch notes
- Order history and frequently ordered items
- Exclusive B2B offers
and much more...
Details
- Circuit breakers and fuses
- Earth leakage circuit breaker
- 1 KOM
- LEGRAND
DetailsTechnical specifications
Technical specifications
Built-in depth
44.5mm
Rated voltage
230V
Rated current
6A
Rated fault current
0.01A
Surge current capacity
-kA
Width in number of modular spacings
45.1
Release characteristic
C
Current limiting class
1
Rated insulation voltage Ui
-V
Leakage current type
Other
Over voltage category
-
Frequency
50/60 Hz
Pollution degree
-
Degree of protection (IP)
IP20
Connectable conductor cross section solid-core
2.5 .. 2.5mm²
Number of protected poles
1
Ambient temperature during operating
-5 .. 50°C
Rated short-circuit breaking capacity according to IEC 60947-2
1.5kA
Anti-nuisance tripping version
Connectable conductor cross section multi-wired
- .. -mm²
With interlocking device
Number of poles (total)
1
Concurrently switching neutral conductor
Rated impulse withstand voltage Uimp
-kV
Rated short-circuit breaking capacity according to EN 61009
1.5kA
Rated short-circuit breaking capacity Icn according to EN 61009-1
1.5kA
