Details
- •Circuit breakers and fuses
- •Earth leakage circuit breaker
- •1 KOM
- •LEGRAND
Technical specifications
Built-in depth33.5mm
Rated insulation voltage Ui-V
Rated voltage230V
Rated current6A
Release characteristicC
Rated fault current0.01A
Surge current capacity-kA
Leakage current typeOther
Over voltage category-
Pollution degree-
Concurrently switching neutral conductorYes
Degree of protection (IP)IP20
Width in number of modular spacings43.8
Current limiting class1
Number of protected poles1
Connectable conductor cross section multi-wired- - -mm²
Rated short-circuit breaking capacity according to IEC 60947-21.5kA
Connectable conductor cross section solid-core2.5 - 2.5mm²
Frequency50/60 Hz
With interlocking deviceNo
Rated short-circuit breaking capacity Icn according to EN 61009-11.5kA
Rated short-circuit breaking capacity according to EN 610091.5kA
Number of poles (total)1
Rated impulse withstand voltage Uimp-kV
Anti-nuisance tripping versionNo
Ambient temperature during operating-5 - 50°C
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
L4305/6 | RCD+MCB 1P+N 6A 10MA 1500A-2M
