Details

  • •Low-voltage industrial components
  • •Switch disconnector
  • •1 KOM
  • •LEGRAND

Technical specifications

Number of poles3
Type of control elementShort thumb-grip
Number of auxiliary contacts as normally closed contact0
Rated permanent current Iu25A
Number of auxiliary contacts as normally open contact0
Motor drive integratedNo
Motor drive optionalNo
Type of electrical connection of main circuitScrew connection
Number of auxiliary contacts as change-over contact0
Device constructionBuilt-in device fixed built-in technique
Rated operation power at AC-3, 400 V5.5kW
Degree of protection (IP), front sideIP65
Suitable for floor mountingNo
Suitable for intermediate mountingNo
Suitable for distribution board installationNo
Max. rated operation voltage Ue AC400V
Rated operating voltage690 - 690V
Conditioned rated short-circuit current Iq10kA
Rated operation power at AC-23, 400 V7.5kW
InterlockableYes
Suitable for front mounting 4-holeYes
Voltage release optionalNo
Version as maintenance-/service switchYes
Switching power at 400 V10kW
Rated short-time withstand current lcw1kA
Version as safety switchYes
Colour control elementRed
Suitable for front mounting centreNo
Version as emergency stop installationNo
Rated permanent current at AC-21, 400 V25A
Number of switches-
Version as reversing switchNo
Rated permanent current at AC-23, 400 V-A
Version as main switchYes
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user

022102 | RASTAVNA SKLOPKA 3P 25A

Main Product Image

Details

  • Low-voltage industrial components
  • Switch disconnector
  • 1 KOM
  • LEGRAND

Technical specifications

Number of poles

3

Type of control element

Short thumb-grip

Number of auxiliary contacts as normally closed contact

0

Rated permanent current Iu

25A

Number of auxiliary contacts as normally open contact

0

Motor drive integrated

Motor drive optional

Type of electrical connection of main circuit

Screw connection

Number of auxiliary contacts as change-over contact

0

Device construction

Built-in device fixed built-in technique

Rated operation power at AC-3, 400 V

5.5kW

Degree of protection (IP), front side

IP65

Suitable for floor mounting

Suitable for intermediate mounting

Suitable for distribution board installation

Max. rated operation voltage Ue AC

400V

Rated operating voltage

690 .. 690V

Conditioned rated short-circuit current Iq

10kA

Rated operation power at AC-23, 400 V

7.5kW

Interlockable

Suitable for front mounting 4-hole

Voltage release optional

Version as maintenance-/service switch

Switching power at 400 V

10kW

Rated short-time withstand current lcw

1kA

Version as safety switch

Colour control element

Red

Suitable for front mounting centre

Version as emergency stop installation

Rated permanent current at AC-21, 400 V

25A

Number of switches

-

Version as reversing switch

Rated permanent current at AC-23, 400 V

-A

Version as main switch
