022109 | Rastavna Sklopka 3P 20A
Code: 1770328
ManufacturerLegrand
Catalog number022109
TypeLegrand 022109
CategorySwitch disconnector
EAN code3245060221096
Details
- •Low-voltage industrial components
- •Switch disconnector
- •1 KOM
- •LEGRAND
Technical specifications
Rated operation power at AC-3, 400 V4kW
Number of auxiliary contacts as normally open contact1
Rated operating voltage690 - 690V
Conditioned rated short-circuit current Iq-kA
Number of auxiliary contacts as normally closed contact1
Type of control elementShort thumb-grip
InterlockableYes
Version as main switchYes
Degree of protection (IP), front sideIP65
Number of switches-
Version as maintenance-/service switchYes
Type of electrical connection of main circuitScrew connection
Number of auxiliary contacts as change-over contact0
Motor drive integratedNo
Version as safety switchYes
Rated operation power at AC-23, 400 V7.5kW
Rated short-time withstand current lcw1kA
Version as emergency stop installationNo
Colour control elementRed
Switching power at 400 V8kW
Suitable for intermediate mountingNo
Suitable for front mounting centreNo
Rated permanent current at AC-21, 400 V20A
Suitable for floor mountingNo
Device constructionBuilt-in device fixed built-in technique
Suitable for distribution board installationNo
Voltage release optionalNo
Motor drive optionalNo
Suitable for front mounting 4-holeYes
Rated permanent current at AC-23, 400 V-A
Version as reversing switchNo
Rated permanent current Iu20A
Number of poles3
Max. rated operation voltage Ue AC400V
