Details
- •Low-voltage industrial components
- •Switch disconnector
- •1 KOM
- •LEGRAND
Technical specifications
Number of auxiliary contacts as normally closed contact1
Conditioned rated short-circuit current Iq6kA
Number of poles3
Number of auxiliary contacts as normally open contact1
Rated operating voltage690 - 690V
Rated permanent current Iu20A
Rated operation power at AC-3, 400 V4kW
Suitable for floor mountingYes
Motor drive integratedNo
Degree of protection (IP), front sideIP65
Rated operation power at AC-23, 400 V7.5kW
Suitable for distribution board installationNo
Number of auxiliary contacts as change-over contact0
Suitable for front mounting 4-holeNo
Suitable for intermediate mountingNo
Number of switches-
Suitable for front mounting centreNo
Motor drive optionalNo
Version as main switchYes
Rated short-time withstand current lcw1kA
Version as emergency stop installationNo
Version as safety switchYes
InterlockableYes
Version as maintenance-/service switchYes
Colour control elementRed
Max. rated operation voltage Ue AC400V
Type of electrical connection of main circuitScrew connection
Voltage release optionalNo
Rated permanent current at AC-21, 400 V20A
Switching power at 400 V8kW
Device constructionComplete device in housing
Type of control elementShort thumb-grip
Rated permanent current at AC-23, 400 V-A
Version as reversing switchNo
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
022179 | RASTAVNA SKLOPKA 3P 20A N/Z
Why Register?
- View wholesale prices with discounts
- Real-time stock availability
- Access invoices and dispatch notes
- Order history and frequently ordered items
- Exclusive B2B offers
and much more...
Details
- Low-voltage industrial components
- Switch disconnector
- 1 KOM
- LEGRAND
DetailsTechnical specifications
Technical specifications
Number of auxiliary contacts as normally closed contact
1
Conditioned rated short-circuit current Iq
6kA
Number of poles
3
Number of auxiliary contacts as normally open contact
1
Rated operating voltage
690 .. 690V
Rated permanent current Iu
20A
Rated operation power at AC-3, 400 V
4kW
Suitable for floor mounting
Motor drive integrated
Degree of protection (IP), front side
IP65
Rated operation power at AC-23, 400 V
7.5kW
Suitable for distribution board installation
Number of auxiliary contacts as change-over contact
0
Suitable for front mounting 4-hole
Suitable for intermediate mounting
Number of switches
-
Suitable for front mounting centre
Motor drive optional
Version as main switch
Rated short-time withstand current lcw
1kA
Version as emergency stop installation
Version as safety switch
Interlockable
Version as maintenance-/service switch
Colour control element
Red
Max. rated operation voltage Ue AC
400V
Type of electrical connection of main circuit
Screw connection
Voltage release optional
Rated permanent current at AC-21, 400 V
20A
Switching power at 400 V
8kW
Device construction
Complete device in housing
Type of control element
Short thumb-grip
Rated permanent current at AC-23, 400 V
-A
Version as reversing switch
