Details
- •Low-voltage industrial components
- •Switch disconnector
- •1 KOM
- •LEGRAND
Technical specifications
Rated operating voltage500 - 500V
Degree of protection (IP), front sideIP2X
Number of auxiliary contacts as change-over contact0
Number of auxiliary contacts as normally closed contact0
Rated operation power at AC-3, 400 V-kW
Number of auxiliary contacts as normally open contact0
Rated permanent current Iu32A
Number of poles4
Conditioned rated short-circuit current Iq-kA
Version as main switchYes
InterlockableYes
Type of electrical connection of main circuitScrew connection
Version as emergency stop installationYes
Type of control elementToggle
Number of switches-
Motor drive integratedNo
Rated operation power at AC-23, 400 V17kW
Version as maintenance-/service switchYes
Version as safety switchYes
Colour control elementRed
Suitable for floor mountingNo
Rated short-time withstand current lcw0.5kA
Suitable for front mounting centreYes
Suitable for front mounting 4-holeYes
Suitable for distribution board installationYes
Suitable for intermediate mountingNo
Motor drive optionalNo
Voltage release optionalNo
Switching power at 400 V17kW
Device constructionBuilt-in device fixed built-in technique
Version as reversing switchNo
Rated permanent current at AC-23, 400 V-A
Max. rated operation voltage Ue AC500V
Rated permanent current at AC-21, 400 V32A
