Details
- •Terminal blocks
- •(Knife) disconnect terminal block
- •5 KOM
- •LEGRAND
Technical specifications
Inflammability class of insulation material according to with UL94V2
Type of slittingSwivelling
Connectable conductor cross section fine-strand with cable end sleeve- - -mm²
Type of electrical connection 1Screw connection
Height113.5mm
With integrated test socketYes
Number of levels1
Width55mm
ColourGrey
Type of electrical connection 2Bolt connection
Closing plate requiredNo
Depth337mm
Operating temperature-5 - 40°C
Internally connected stagesNo
Number of clamp positions per level1
Material insulation bodyThermoplastic
Connectable conductor cross section fine-strand without cable end sleeve70 - 300mm²
Connectable conductor cross section multi-wired70 - 300mm²
Mounting methodDIN rail (top hat rail) 35 mm
Rated voltage1000V
Connectable conductor cross section solid-core70 - 300mm²
Rated current In570A
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
