Details

  • •Low-voltage industrial components
  • •One-phase control transformer
  • •1 KOM
  • •LEGRAND

Technical specifications

Type of insulation material according to IEC 85B
Height70mm
Primary voltage 2400 - 400V
Ring coreNo
Suitable for mounting on PCBNo
Modular versionYes
Primary voltage 4- - -V
Built as energy saving transformerNo
Short-circuit-proofNo
Width84mm
Built as isolating transformerNo
Primary voltage 5- - -V
Built as safety transformerYes
Depth98mm
Primary voltage 6- - -V
Primary voltage 3- - -V
Primary voltage 10- - -V
Relative short circuit voltage15.61702%
Primary voltage 9- - -V
Primary voltage 7- - -V
Primary voltage 8- - -V
Secondary voltage 224 - 24V
Secondary voltage 3- - -V
Secondary voltage 5- - -V
Secondary voltage 8- - -V
Secondary voltage 6- - -V
Secondary voltage 7- - -V
Secondary voltage 9- - -V
Secondary voltage 4- - -V
Secondary voltage 10- - -V
Degree of protection (IP)IP2X
Primary voltage 1230 - 230V
Secondary voltage 112 - 12V
Rated apparent power40VA
