Details
- •Luminaires
- •Ceiling-/wall luminaire
- •12 KOM
- •LEGRAND
Technical specifications
Protection classII
Type of control gearNot required
Type of gridNone
With movement sensorNo
Suitable for lamp power60 - 60W
Lamp holderE27
Voltage typeAC
Colour housingGrey
Conductor cross section-mm²
Width126mm
Outer diameter-mm
Built-in length178mm
Suitable for suspended mountingNo
Light outletDirect
Built-in diameter-mm
Height/depth108mm
Lamp typeIncandescent lamp
With light sensorNo
Built-in width-mm
Suitable for light line configurationNo
Material housingPlastic
Suitable for emergency lightingNo
Length178mm
Number of poles-
Colour rendering index CRI90-100
Luminaire with limited surface temperature, sign "D“No
Suitable for wall mountingYes
With light sourceNo
Suitable for built-in mountingNo
Degree of protection (IP)IP44
Covering of the luminaire with thermally insulating material possibleNo
Suitable for number of lamps1
Impact strengthIK06
Material coverGlass structured
Nominal voltage110 - 230V
Light sharingAsymmetric
Rated life time L70/B50 at 25 °C-h
Max. system power60W
Rated luminous flux according to IEC 62722-2-1710lm
Rated life time L70/B10 at 25 °C-h
Colour of lightWhite
Suitable for surface mountingYes
With control gearNo
With air slotsNo
Rated life time L80/B50 at 25 °C-h
Rated life time L80/B10 at 25 °C-h
Suitable for workplace according to EN 12464-1No
Beam angleExtreme wide beam >80°
Colour temperature2700 - 2700K
LED nominal current at constant current261 - 545mA
Dimming DMXNo
Dimming 0-10 VNo
Dimming DALINo
Rated life time L90/B50 at 25 °C-h
Rated life time L90/B10 at 25 °C-h
Rated ambient temperature according to IEC62722-2-1-10 - 40°C
Dimming 1-10 VNo
Dimming Sine Wave ReductionNo
Dimming mains voltage modulationNo
Dimming RFNo
Dimming programmableNo
Dimming Touch and DimNo
Dimming LineSwitchNo
Dimming phase cut-offNo
Dimming phase cut-onNo
Dimming GPRSNo
Dimming potentiometer (integrated)No
Dimming manufacturer's proprietary systemNo
Dimming with push-buttonNo
No dim functionYes
Dimming ZigbeeNo
Dimming depending on control gearNo
Dimming DSINo
Power factor-
Luminaire efficacy-lm/W
Built-in height/depth-mm
Suitable for ceiling mountingYes
Light distributorDiffuser lens/optic/panel
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
