Details
- •Luminaires
- •Ceiling-/wall luminaire
- •10 KOM
- •LEGRAND
Technical specifications
Protection classII
Outer diameter230mm
Width230mm
Conductor cross section-mm²
Colour housingWhite
Lamp holderE27
Voltage typeAC
With movement sensorNo
Colour rendering index CRI90-100
Built-in diameter-mm
Built-in width-mm
Suitable for suspended mountingNo
Type of gridNone
Number of poles-
Type of control gearNot required
Suitable for lamp power70 - 70W
With light sensorNo
Length230mm
Suitable for light line configurationNo
Light sharingAsymmetric
Light outletDirect
Built-in length230mm
Suitable for emergency lightingNo
Impact strengthIK07
Lamp typeIncandescent lamp
Nominal voltage110 - 230V
Material housingPlastic
Degree of protection (IP)IP44
Material coverPlastic, opal
Height/depth105mm
With light sourceNo
Luminaire with limited surface temperature, sign "D“No
Suitable for wall mountingYes
Max. system power70W
Suitable for built-in mountingNo
Suitable for surface mountingYes
Suitable for workplace according to EN 12464-1No
Covering of the luminaire with thermally insulating material possibleNo
With control gearNo
Colour of lightWhite
Rated luminous flux according to IEC 62722-2-11200lm
Suitable for number of lamps1
Colour temperature2700 - 2700K
Beam angleExtreme wide beam >80°
Rated life time L80/B10 at 25 °C-h
Rated life time L90/B10 at 25 °C-h
Rated ambient temperature according to IEC62722-2-1-10 - 40°C
With air slotsNo
Rated life time L70/B10 at 25 °C-h
Rated life time L80/B50 at 25 °C-h
Rated life time L70/B50 at 25 °C-h
Rated life time L90/B50 at 25 °C-h
LED nominal current at constant current304 - 636mA
Dimming 0-10 VNo
Dimming 1-10 VNo
Dimming DMXNo
Dimming DALINo
Dimming phase cut-offNo
Dimming phase cut-onNo
Dimming LineSwitchNo
Dimming manufacturer's proprietary systemNo
Dimming GPRSNo
Dimming Sine Wave ReductionNo
Dimming mains voltage modulationNo
Dimming RFNo
Dimming potentiometer (integrated)No
Dimming programmableNo
Dimming with push-buttonNo
Dimming Touch and DimNo
Dimming ZigbeeNo
No dim functionYes
Dimming DSINo
Light distributorDiffuser lens/optic/panel
Dimming depending on control gearNo
Luminaire efficacy-lm/W
Built-in height/depth-mm
Suitable for ceiling mountingYes
Power factor-
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
