Details
- •Domestic switching devices
- •Socket outlet
- •10 KOM
- •LEGRAND
Technical specifications
Nominal current16A
Number of units1
Nominal voltage250V
LockableNo
Halogen freeYes
ModelProtective contact (SCHUKO)
Mounting methodFlush mounted (plaster)
ColourGrey
Number of phases1
Surface protectionUntreated
With hinged lidYes
With signal lampNo
Connection typeScrewed terminal
RAL-number (similar)7046
Frequency50 - 60Hz
Imprint/indicationDegree of protection (IP)
Rated fault current-mA
Rotated central insertNo
With on/off switchNo
With enhanced contact protectionYes
Impact strengthIK07
For heavy conditions (according to VDE)No
Fault current protectionNo
Label space/information surfaceNo
Insulated mountingNo
Type of fasteningMounting with screw
Protective contactYes
Over voltage protectionNo
MaterialPlastic
Eject-mechanismNo
Special power supplyNo special power supply
Material qualityThermoplastic
TransparentNo
Surface finishingMatt
Width of device86mm
With loop through functionYes
Suitable for degree of protection (IP)IP55
With miniature fuseNo
Depth of device46mm
Number of socket outlets switchable0
Height of device86mm
With orientation lightingNo
Number of modules (module system)-
With built-in USB power supplyNo
With function lightingNo
Number of active pins (round)1
Min. depth of built-in installation box-mm
Protective earth pin roundNo
Number of active pins (flat)0
Anti-bacterial treatmentNo
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
069833 | IP55 UTICNICA 2P+E SIVA
Why Register?
- View wholesale prices with discounts
- Real-time stock availability
- Access invoices and dispatch notes
- Order history and frequently ordered items
- Exclusive B2B offers
and much more...
Details
- Domestic switching devices
- Socket outlet
- 10 KOM
- LEGRAND
DetailsTechnical specifications
Technical specifications
Nominal current
16A
Number of units
1
Nominal voltage
250V
Lockable
Halogen free
Model
Protective contact (SCHUKO)
Mounting method
Flush mounted (plaster)
Colour
Grey
Number of phases
1
Surface protection
Untreated
With hinged lid
With signal lamp
Connection type
Screwed terminal
RAL-number (similar)
7046
Frequency
50 .. 60Hz
Imprint/indication
Degree of protection (IP)
Rated fault current
-mA
Rotated central insert
With on/off switch
With enhanced contact protection
Impact strength
IK07
For heavy conditions (according to VDE)
Fault current protection
Label space/information surface
Insulated mounting
Type of fastening
Mounting with screw
Protective contact
Over voltage protection
Material
Plastic
Eject-mechanism
Special power supply
No special power supply
Material quality
Thermoplastic
Transparent
Surface finishing
Matt
Width of device
86mm
With loop through function
Suitable for degree of protection (IP)
IP55
With miniature fuse
Depth of device
46mm
Number of socket outlets switchable
0
Height of device
86mm
With orientation lighting
Number of modules (module system)
-
With built-in USB power supply
With function lighting
Number of active pins (round)
1
Min. depth of built-in installation box
-mm
Protective earth pin round
Number of active pins (flat)
0
Anti-bacterial treatment
VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user.
