Details
- •Connection devices
- •Box/housing for built-in mounting in the wall/ceiling
- •10 KOM
- •LEGRAND
Technical specifications
ModelDouble
Width72mm
ColourOrange
Mounting methodOther
Internal depth38mm
ShapeOval
Construction typeDevice connection box (round/square)
Equipped withNone
SealableNo
Diameter67mm
Surface protectionUntreated
Length143mm
Halogen freeYes
ConnectableNo
Cover attachmentOther
With screeningNo
Max. conductor cross section0mm²
Luminaire hook mountingNo
Circuit integrityNone
MaterialPlastic
For number of electric fittings5
Mounting switching equipmentScrew or spread out
Number of inlets5
With nail lugsNo
Degree of protection (IP)IP20
With screwsYes
Air tightNo
Suitable for cable diameter20 - 25mm
Depth- - -mm
NozzleNone
Number of poles of the clamp0
For tube diameter20/25 mm
Provided with revolving ringNo
Clamp position fixedNo
Pipe lockingNo
Inlet from the rearYes
Housing feed-through by step membraneNo
Housing feed-through by seal membraneNo
Housing feed-through by nozzleNo
Housing feed-through by break-out openingNo
Pipe locking optionalNo
Cover modelNone
Number of included spouts-
Transparent coverNo
