Details

  • •Circuit breakers and fuses
  • •Earth leakage circuit breaker
  • •Minimum order quantity: 1 pcs
  • •LEGRAND

Technical specifications

Built-in depth44mm
Rated insulation voltage Ui-V
Rated voltage230V
Voltage typeAC
Current limiting class3
Over voltage category-
Pollution degree2
Release characteristicC
Width in number of modular spacings2
Connectable conductor cross section solid-core0.75 - 16mm²
Number of protected poles1
Suitable for flush-mounted installationYes
Concurrently switching neutral conductorYes
Rated short-circuit breaking capacity according to IEC 60947-26kA
Surge current capacity0.25kA
Degree of protection (IP)IP20
Connectable conductor cross section multi-wired0.75 - 10mm²
Frequency50 Hz
With interlocking deviceYes
Rated short-circuit breaking capacity according to EN 610096kA
Anti-nuisance tripping versionNo
Rated impulse withstand voltage Uimp-kV
Rated short-circuit breaking capacity Icn according to EN 61009-16kA
Ambient temperature during operating- - -°C
Rated current10A
Rated fault current0.03A
Leakage current typeAC
Number of poles (total)2
