Details

  • •Circuit breakers and fuses
  • •Earth leakage circuit breaker
  • •Minimum order quantity: 1 pcs
  • •LEGRAND

Technical specifications

Built-in depth44mm
Voltage typeAC
Rated voltage230V
Release characteristicC
Concurrently switching neutral conductorYes
Surge current capacity0.25kA
Pollution degree2
Connectable conductor cross section solid-core0.75 - 16mm²
Rated insulation voltage Ui-V
Rated impulse withstand voltage Uimp-kV
Degree of protection (IP)IP20
Width in number of modular spacings2
With interlocking deviceYes
Number of protected poles1
Anti-nuisance tripping versionNo
Frequency50 Hz
Suitable for flush-mounted installationYes
Ambient temperature during operating- - -°C
Rated short-circuit breaking capacity according to IEC 60947-26kA
Connectable conductor cross section multi-wired0.75 - 10mm²
Over voltage category-
Rated short-circuit breaking capacity according to EN 610096kA
Rated short-circuit breaking capacity Icn according to EN 61009-16kA
Current limiting class3
Rated current20A
Rated fault current0.03A
Leakage current typeA
Number of poles (total)2
