Details

  • •Circuit breakers and fuses
  • •Earth leakage circuit breaker
  • •Minimum order quantity: 1 pcs
  • •LEGRAND

Technical specifications

Connectable conductor cross section solid-core- - -mm²
Rated voltage400V
Voltage typeAC
Degree of protection (IP)IP20
Built-in depth44mm
Current limiting class1
Number of protected poles4
Ambient temperature during operating- - -°C
Rated insulation voltage Ui-V
Suitable for flush-mounted installationYes
Frequency50 Hz
Release characteristicB
Pollution degree2
With interlocking deviceYes
Connectable conductor cross section multi-wired- - -mm²
Over voltage category-
Surge current capacity0.25kA
Concurrently switching neutral conductorYes
Width in number of modular spacings4
Rated short-circuit breaking capacity according to IEC 60947-210kA
Rated short-circuit breaking capacity according to EN 610096kA
Anti-nuisance tripping versionNo
Rated impulse withstand voltage Uimp-kV
Rated short-circuit breaking capacity Icn according to EN 61009-16kA
Rated current20A
Rated fault current0.03A
Leakage current typeA
Number of poles (total)4
