Details
- •Circuit breakers and fuses
- •Earth leakage circuit breaker
- •1 KOM
- •LEGRAND
Technical specifications
Leakage current typeA
Rated voltage400V
Concurrently switching neutral conductorYes
Voltage typeAC
Release characteristicB
Surge current capacity0.25kA
Rated current25A
Over voltage category-
With interlocking deviceYes
Number of poles (total)4
Width in number of modular spacings4
Rated fault current0.3A
Connectable conductor cross section solid-core- - -mm²
Frequency50 Hz
Current limiting class1
Rated short-circuit breaking capacity according to IEC 60947-210kA
Ambient temperature during operating- - -°C
Number of protected poles4
Suitable for flush-mounted installationYes
Degree of protection (IP)IP20
Pollution degree2
Rated insulation voltage Ui-V
Built-in depth44mm
Connectable conductor cross section multi-wired- - -mm²
Anti-nuisance tripping versionNo
Rated short-circuit breaking capacity Icn according to EN 61009-16kA
Rated short-circuit breaking capacity according to EN 610096kA
Rated impulse withstand voltage Uimp-kV
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
411231 | KZS DX3 4P B25 10KA A 300MA
