Details
- •Circuit breakers and fuses
- •Residual current circuit breaker (RCCB)
- •1 KOM
- •LEGRAND
Technical specifications
Rated fault current30mA
Mounting methodDIN rail
Rated voltage230V
Leakage current typeAC
Number of poles2
Built-in depth44mm
Rated insulation voltage Ui250V
Rated current80A
Width in number of modular spacings2
Surge current capacity0.25kA
Connectable conductor cross section multi-wired0.75 - 35mm²
With interlocking deviceYes
Selective protectionNo
Rated impulse withstand voltage Uimp4kV
Degree of protection (IP)IP20
Frequency50 Hz
Connectable conductor cross section solid-core0.75 - 50mm²
Pollution degree2
Additional equipment possibleYes
Short-time delayed trippingNo
Ambient temperature during operating-25 - 60°C
Short-circuit breaking capacity (Icw)10kA
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
411512 | TX3 FID 2P 80A AC 30MA
