Details
- •Circuit breakers and fuses
- •Residual current circuit breaker (RCCB)
- •1 KOM
- •LEGRAND
Technical specifications
Short-circuit breaking capacity (Icw)10kA
Built-in depth44mm
Rated insulation voltage Ui250V
Rated voltage230V
Selective protectionYes
Surge current capacity3kA
Number of poles2
Rated fault current300mA
Mounting methodDIN rail
Leakage current typeA
Rated current63A
Connectable conductor cross section solid-core0.75 - 50mm²
Pollution degree2
Degree of protection (IP)IP20
Width in number of modular spacings2
Frequency50 Hz
Short-time delayed trippingYes
With interlocking deviceYes
Ambient temperature during operating-25 - 60°C
Additional equipment possibleYes
Connectable conductor cross section multi-wired0.75 - 35mm²
Rated impulse withstand voltage Uimp4kV
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
411587 | TX3 FID 2P 63A A-S 500MA
