Details
- •Circuit breakers and fuses
- •Residual current circuit breaker (RCCB)
- •1 KOM
- •LEGRAND
Technical specifications
Mounting methodDIN rail
Built-in depth44mm
Rated insulation voltage Ui500V
Leakage current typeA
Pollution degree2
Frequency50 Hz
Connectable conductor cross section solid-core0.75 - 50mm²
Connectable conductor cross section multi-wired0.75 - 35mm²
Short-time delayed trippingNo
Degree of protection (IP)IP20
With interlocking deviceYes
Rated current100A
Number of poles4
Rated fault current0.03A
Rated impulse withstand voltage Uimp4kV
Selective protectionNo
Additional equipment possibleYes
Width in number of modular spacings4
Rated voltage400V
Ambient temperature during operating-25 - 60°C
Surge current capacity0.25kA
Short-circuit breaking capacity (Icw)10kA
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
411768 | TX3 FID 4PD 100A A 30MA
