412253 | ODV PREN KL1+KL2 50KA 4P
Code: 1779167
Details
- •Earthing, lightning and surge protection
- •Surge protection device for power supply systems
- •1 KOM
- •LEGRAND
Technical specifications
Degree of protection (IP)IP20
Mounting methodDIN rail (top hat rail) 35 mm
Construction size4 modular spacing
Max. continuous voltage AC320V
Number of conductors (without earthing)4
Signalling at the deviceOptic
Max. continuous voltage DC-V
Voltage protection level1.7kV
Nominal voltage AC400V
Voltage protection level L-N-kV
Max. conductor cross section flexible (fine-strand)25mm²
Max. conductor cross section solid (solid, stranded)35mm²
Integrated backup fuseNo
Nominal voltage DC-V
With remote signalling contactNo
Nominal discharge surge current (8/20)20kA
Voltage protection level N-PE-kV
System configuration TNNo
System configuration TN-SYes
System configuration DCNo
System configuration ITNo
System configuration otherNo
System configuration TTNo
System configuration TN-CNo
System configuration TN-C-SNo
Max. PV-voltage-V
Category type 2Yes
Max. discharge surge current (8/20)-kA
Short-circuit breaking capacity (Isccr)-kA
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
