412254 | ODV PREN KL1+KL2 50KA 2P
Code: 1779168
Details
- •Earthing, lightning and surge protection
- •Surge protection device for power supply systems
- •1 KOM
- •LEGRAND
Technical specifications
Degree of protection (IP)IP20
Mounting methodDIN rail (top hat rail) 35 mm
Construction size2 modular spacing
Max. continuous voltage AC320V
Number of conductors (without earthing)2
Signalling at the deviceOptic
Max. continuous voltage DC-V
Voltage protection level-kV
Nominal voltage AC230V
Voltage protection level L-N2kV
Max. conductor cross section flexible (fine-strand)25mm²
Max. conductor cross section solid (solid, stranded)35mm²
Integrated backup fuseNo
Nominal voltage DC-V
With remote signalling contactNo
Nominal discharge surge current (8/20)20kA
Voltage protection level N-PE1.5kV
System configuration TNNo
System configuration TN-SNo
System configuration DCNo
System configuration ITNo
System configuration otherNo
System configuration TTYes
System configuration TN-CNo
System configuration TN-C-SNo
Max. PV-voltage-V
Category type 2Yes
Max. discharge surge current (8/20)-kA
Short-circuit breaking capacity (Isccr)-kA
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
412254 | ODV PREN KL1+KL2 50KA 2P
Details
- Earthing, lightning and surge protection
- Surge protection device for power supply systems
- 1 KOM
- LEGRAND
DetailsTechnical specifications
Technical specifications
Degree of protection (IP)
IP20
Mounting method
DIN rail (top hat rail) 35 mm
Construction size
2 modular spacing
Max. continuous voltage AC
320V
Number of conductors (without earthing)
2
Signalling at the device
Optic
Max. continuous voltage DC
-V
Voltage protection level
-kV
Nominal voltage AC
230V
Voltage protection level L-N
2kV
Max. conductor cross section flexible (fine-strand)
25mm²
Max. conductor cross section solid (solid, stranded)
35mm²
Integrated backup fuse
Nominal voltage DC
-V
With remote signalling contact
Nominal discharge surge current (8/20)
20kA
Voltage protection level N-PE
1.5kV
System configuration TN
System configuration TN-S
System configuration DC
System configuration IT
System configuration other
System configuration TT
System configuration TN-C
System configuration TN-C-S
Max. PV-voltage
-V
Category type 2
Max. discharge surge current (8/20)
-kA
Short-circuit breaking capacity (Isccr)
-kA
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user.
