Details
- •Earthing, lightning and surge protection
- •Surge protection device for power supply systems
- •1 KOM
- •LEGRAND
Technical specifications
Number of conductors (without earthing)4
Mounting methodDIN rail (top hat rail) 35 mm
Construction size4 modular spacing
With remote signalling contactNo
Max. continuous voltage AC320V
Voltage protection level-kV
Max. continuous voltage DC-V
Voltage protection level L-N2kV
Signalling at the deviceOptic
Category type 2Yes
Nominal voltage DC-V
System configuration TNNo
Integrated backup fuseNo
System configuration DCNo
Voltage protection level N-PE1.5kV
Max. PV-voltage-V
System configuration TN-SNo
Max. conductor cross section solid (solid, stranded)35mm²
Max. conductor cross section flexible (fine-strand)25mm²
System configuration TN-CNo
System configuration otherNo
Max. discharge surge current (8/20)-kA
System configuration TN-C-SNo
System configuration TTYes
Short-circuit breaking capacity (Isccr)-kA
System configuration ITNo
Nominal discharge surge current (8/20)20kA
Nominal voltage AC400V
Degree of protection (IP)IP20
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
412255 | ODV Pren KL1+KL2 50KA 4P
