Details
- •Earthing, lightning and surge protection
- •Surge protection device for power supply systems
- •1 KOM
- •LEGRAND
Technical specifications
Mounting methodDIN rail (top hat rail) 35 mm
With remote signalling contactNo
Number of conductors (without earthing)2
Construction size2 modular spacing
Degree of protection (IP)IP20
Category type 2Yes
Voltage protection level-kV
Nominal discharge surge current (8/20)20kA
Signalling at the deviceOptic
Max. continuous voltage AC320V
Voltage protection level L-N2kV
System configuration DCNo
Nominal voltage AC230V
Max. conductor cross section solid (solid, stranded)35mm²
Max. PV-voltage-V
System configuration TNNo
Voltage protection level N-PE1.5kV
System configuration TN-SNo
Integrated backup fuseNo
Nominal voltage DC-V
Max. continuous voltage DC-V
System configuration TN-CNo
System configuration ITNo
Max. conductor cross section flexible (fine-strand)25mm²
System configuration TN-C-SNo
System configuration otherNo
Short-circuit breaking capacity (Isccr)-kA
System configuration TTYes
Max. discharge surge current (8/20)-kA
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
412256 | ODV PREN KL1+KL2 50KA 2P
