Details
- •Earthing, lightning and surge protection
- •Surge protection device for power supply systems
- •1 KOM
- •LEGRAND
Technical specifications
Mounting methodDIN rail (top hat rail) 35 mm
Nominal voltage DC-V
With remote signalling contactNo
Category type 2Yes
Construction size2 modular spacing
Max. continuous voltage AC320V
Voltage protection level1.9kV
Number of conductors (without earthing)2
Voltage protection level L-N-kV
Max. PV-voltage-V
Signalling at the deviceOptic
Max. continuous voltage DC-V
Max. conductor cross section solid (solid, stranded)35mm²
Integrated backup fuseNo
Voltage protection level N-PE-kV
Max. conductor cross section flexible (fine-strand)25mm²
Max. discharge surge current (8/20)-kA
System configuration ITNo
System configuration TN-CNo
System configuration TN-C-SNo
System configuration DCNo
System configuration TTNo
System configuration TN-SYes
System configuration otherNo
Short-circuit breaking capacity (Isccr)-kA
System configuration TNNo
Nominal discharge surge current (8/20)25kA
Nominal voltage AC230V
Degree of protection (IP)IP20
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
412271 | ODV Pren KL1+KL2 60KA 2P
