412272 | ODV PREN KL1+KL2 60KA 3P +SD
Code: 1779182
Details
- •Earthing, lightning and surge protection
- •Surge protection device for power supply systems
- •1 KOM
- •LEGRAND
Technical specifications
Degree of protection (IP)IP20
Mounting methodDIN rail (top hat rail) 35 mm
Construction size3 modular spacing
Max. continuous voltage AC320V
Signalling at the deviceOptic
Number of conductors (without earthing)3
Max. continuous voltage DC-V
Voltage protection level1.9kV
Nominal voltage AC400V
Voltage protection level L-N-kV
Max. conductor cross section flexible (fine-strand)25mm²
Max. conductor cross section solid (solid, stranded)35mm²
Integrated backup fuseNo
With remote signalling contactYes
Nominal voltage DC-V
Nominal discharge surge current (8/20)25kA
Voltage protection level N-PE-kV
System configuration DCNo
System configuration TNNo
System configuration TN-SNo
System configuration ITNo
System configuration TTNo
System configuration TN-CYes
System configuration TN-C-SNo
System configuration otherNo
Max. PV-voltage-V
Category type 2Yes
Max. discharge surge current (8/20)-kA
Short-circuit breaking capacity (Isccr)-kA
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
