Details
- •Earthing, lightning and surge protection
- •Surge protection device for power supply systems
- •1 KOM
- •LEGRAND
Technical specifications
Construction size1 modular spacing
With remote signalling contactNo
Number of conductors (without earthing)-
Voltage protection level-kV
Max. continuous voltage AC320V
Signalling at the deviceOptic
Nominal discharge surge current (8/20)20kA
Max. PV-voltage-V
Integrated backup fuseNo
Voltage protection level L-N2kV
System configuration ITNo
System configuration TN-C-SNo
Voltage protection level N-PE1.5kV
Max. conductor cross section flexible (fine-strand)-mm²
Nominal voltage AC400V
Max. conductor cross section solid (solid, stranded)-mm²
System configuration TN-CNo
Category type 2Yes
Nominal voltage DC-V
Max. continuous voltage DC-V
Short-circuit breaking capacity (Isccr)-kA
System configuration TN-SNo
Max. discharge surge current (8/20)-kA
System configuration TNNo
System configuration otherYes
Degree of protection (IP)IP20
System configuration DCNo
System configuration TTNo
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
412302 | ODV PREN KL1+KL2 50KA MODUL
