Details
- •Low-voltage industrial components
- •Switch disconnector (low voltage)
- •1 KOM
- •LEGRAND
Technical specifications
Rated operation power at AC-3, 400 V-kW
Number of auxiliary contacts as normally open contact0
Rated operating voltage1000 - 1000V
Conditioned rated short-circuit current Iq800kA
Number of auxiliary contacts as normally closed contact0
Suitable for front mounting centreYes
InterlockableYes
Suitable for distribution board installationYes
Colour control elementRed
Version as maintenance-/service switchYes
Rated short-time withstand current lcw0.8kA
Suitable for intermediate mountingNo
Number of switches-
Type of control elementShort thumb-grip
Version as safety switchYes
Suitable for floor mountingNo
Type of electrical connection of main circuitScrew connection
Rated operation power at AC-23, 400 V-kW
Motor drive integratedNo
Version as emergency stop installationYes
Number of auxiliary contacts as change-over contact0
Suitable for front mounting 4-holeYes
Degree of protection (IP), front sideIP2X
Version as main switchYes
Rated permanent current at AC-23, 400 V-A
Switching power at 400 V-kW
Rated permanent current at AC-21, 400 V-A
Version as reversing switchNo
Device constructionBuilt-in device fixed built-in technique
Motor drive optionalNo
Voltage release optionalNo
Rated permanent current Iu63A
Number of poles2
Max. rated operation voltage Ue AC1000V
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
414282 | Fotovol.skl. RUCK.63A 1000V
