Details
- •Circuit breakers and fuses
- •Miniature circuit breaker (MCB)
- •1 KOM
- •LEGRAND
Technical specifications
Voltage typeDC
Built-in depth44mm
Release characteristicB
Rated insulation voltage Ui1000V
Rated current10A
Degree of protection (IP)IP20
Frequency- - -Hz
Rated voltage1000V
Width in number of modular spacings6
Over voltage category-
Explosion-proofNo
Pollution degree2
Current limiting class-
Concurrently switching neutral conductorNo
Connectable conductor cross section multi-wired1.5 - 35mm²
Connectable conductor cross section solid-core1.5 - 50mm²
Number of protected poles2
Flush-mounted installationYes
Additional equipment possibleYes
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V-kA
Rated impulse withstand voltage Uimp8kV
Ambient temperature during operating- - -°C
Number of poles (total)2
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V-kA
Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V-kA
Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V-kA
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
414446 | OSIG. DC 2P B10 1000V DC
