Details
- •Luminaires
- •Emergency luminaire
- •1 KOM
- •LEGRAND
Technical specifications
Protection classII
FunctionEscape route lighting/signage
Mounting methodWall surface mounted
Outer diameter-mm
Width110mm
Conductor cross section2.5mm²
Colour housingWhite
Power supply systemPeripheral (individual battery)
Lamp holderOther
Connection typeOther
Voltage typeAC
Type of control gearLED operating device current-controlled
Material housingPlastic
Built-in width-mm
Battery qualityNiCd
Suitable for labelling typeSticker
Colour temperature6000 - 6000K
Wiring systemContinuous circuit/emergency circuit
Built-in diameter-mm
Number of poles5
Impact strengthIK07
Built-in length-mm
Height/depth41mm
Degree of protection (IP)IP42
With light sourceYes
Nominal voltage230 - 230V
Length210mm
Lamp typeLED not exchangeable
Material coverPlastic, opal
Number of lighting heads1
Type of indicatorOnly single-sided
Suitable for number of lamps-
With remote switch connectionNo
Monitoring equipmentAutomatic self test
Luminaire with limited surface temperature, sign "D“No
Recognition distance-m
Max. system power10W
Rated luminous flux according to IEC 62722-2-1100lm
LED nominal current at constant current43 - 43mA
Rated life time L70/B50 at 25 °C147000h
With pictogramNo
Luminous flux in standby mode100lm
Rated life time L80/B10 at 25 °C-h
Rated life time L90/B50 at 25 °C-h
Rated life time L70/B10 at 25 °C-h
Rated ambient temperature according to IEC62722-2-1- - -°C
Rated life time L80/B50 at 25 °C-h
Rated life time L90/B10 at 25 °C-h
Built-in height/depth-mm
Power factor-
Light distributorDiffuser lens/optic/panel
Energy efficiency class of the built-in lampA++, A+, A (LED)
Nominal operation time1 - 1h
