Details
- •Low-voltage industrial components
- •Switch disconnector
- •1 KOM
- •ABB
Technical specifications
Number of auxiliary contacts as normally open contact0
Rated permanent current Iu-A
Rated operation power at AC-23, 400 V-kW
Version as maintenance-/service switchYes
InterlockableNo
Version as main switchYes
Rated short-time withstand current lcw42kA
Type of control elementLong turning handle
Conditioned rated short-circuit current Iq-kA
Version as emergency stop installationNo
Number of poles4
Version as safety switchNo
Number of auxiliary contacts as change-over contact0
Rated operation power at AC-3, 400 V-kW
Motor drive integratedYes
Type of electrical connection of main circuitBolt connection
Suitable for front mounting 4-holeYes
Suitable for distribution board installationYes
Suitable for front mounting centreNo
Number of auxiliary contacts as normally closed contact0
Suitable for floor mountingNo
Degree of protection (IP), front sideIP20
Rated operating voltage- - -V
Number of switches1
Rated permanent current at AC-21, 400 V-A
Degree of protection (NEMA)1
Device constructionBuilt-in device plug-in technique
Rated permanent current at AC-23, 400 V-A
Switching power at 400 V-kW
Version as reversing switchNo
Motor drive optionalNo
Suitable for intermediate mountingNo
Max. rated operation voltage Ue AC480V
Voltage release optionalNo
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
1SCA151060R1001 | OXB630E3S4QB
