1SCA153521R1001 | OXB400E3X3QB
Code: 1785776
ManufacturerABB
Catalog number1SCA153521R1001
TypeOXB400E3X3QB
CategorySwitch disconnector
EAN code6417019845470
Details
- •Low-voltage industrial components
- •Switch disconnector
- •1 KOM
- •ABB
Technical specifications
Rated operating voltage- - -V
Number of switches1
Number of auxiliary contacts as change-over contact0
Degree of protection (IP), front sideIP20
Number of auxiliary contacts as normally closed contact0
Type of electrical connection of main circuitBolt connection
InterlockableNo
Number of auxiliary contacts as normally open contact0
Motor drive integratedYes
Rated operation power at AC-3, 400 V-kW
Conditioned rated short-circuit current Iq-kA
Version as main switchYes
Version as safety switchNo
Type of control elementLong turning handle
Version as emergency stop installationNo
Rated operation power at AC-23, 400 V-kW
Suitable for front mounting centreNo
Device constructionBuilt-in device plug-in technique
Suitable for floor mountingNo
Motor drive optionalNo
Voltage release optionalNo
Switching power at 400 V-kW
Rated permanent current at AC-21, 400 V-A
Suitable for intermediate mountingNo
Suitable for distribution board installationYes
Rated permanent current at AC-23, 400 V-A
Suitable for front mounting 4-holeYes
Version as reversing switchNo
Rated short-time withstand current lcw25kA
Version as maintenance-/service switchYes
Degree of protection (NEMA)1
Rated permanent current Iu-A
Number of poles3
Max. rated operation voltage Ue AC480V
